Medal Sports FH1412407 - Manual (Page 4)

3
2 3 4 1
x1 x2 x2 x2
6 5
x4
Motor Apron Corner
P1 P2 P3
x4 x2 x1
Main Frame
Felt Pad
14mm Screw
Pusher Round Puck Goal
8 7
x1 x4
Allen Key
x4
10mm Screw EVA Pad
1412407 PARTS LIST
1412407 PRE-INSTALLED PARTS
