FIG.4
14. Place the Plastic Corner (#17) flush with table corner and attach using three Screws (#A1) per Corner.
See FIG. 4A.
15. Place the End Apron (#11) between the corners and flush with the table edge at the Player end of table
using six Screws (#A1) per End Apron. See FIG. 4.
16. Place the Side Apron (#12) flush with table edge at the side of the table using five Screws (#A1) per Side
Apron. See FIG. 4.
NOTE: Make sure the all Aprons are inside the Plastic Corners.
8
X 4
X 44
X 2
X 4
17
A1
11
12
Player
Player
Center
17
17
17
A1
A1
A1
11
12
12
FIG. 4
FIG.4A
