MVVS 80 IRS - Manual (Page 6)

Spare Parts List
Nr. Description Nr. Description
0101 Crankcase 0904 Connecting rod washer
0102 Screw-cap 0951 Connecting rod
0202 Front bearing 2x 1001 Crankshaft
0203 Rear bearing 1101 Drive washer
0204 Packing 1102 Drive washer key
0206 Crankshaft retaining ring 1103 Propeller nut
0301 Rear cover 1104 Propeller washer
0302 Rear cover screws-set 1105 Propeller screw
0303 Rear cover „O“- ring 1107 Propeller screws - set
0304 Pressure nipple
0305 Pressure nipple gasket 1301 Reed valve case
0306 Carburetor flange 1302 Reed valve
0307 Carb. flange gasket 1303 Reed valve screws
0308 Carb. flange screws - set 1304 Reed valve gasket-upper
0401 Cylinder 1305 Reed valve gasket-bottom
0402 Cylinder screws - set 1306 Reed valve strap
0403 Cylinder nut 1307 Carburetor screws
0404 Cylinder gasket 1300 (set) =1301+1302+1303+1305+1306
0405 Exhaust screws - set
0406 Exhaust nut 1405 Ignition sensor fixing screws
0407 Exhaust flange gasket 3309 Spark plug
0701 Piston 3314L Electronic ignition unit (3007L)
0702 Piston ring 3314S Electronic ignition unit (3007SP)
0801 Piston pin 3227 Carburetor
0802 Piston pin retainer
