Magnetic Products 300 Series, Plate Magnets User Manual
Page 2
Advertising
Overall Length "A"
10.5 in
267 mm
Magnetic Face Length "B"
8.5 in
216 mm
Thickness "C"
2.125 in
54 mm
Step Height "D"
0.81 in
21 mm
Effective Magnetic Field Depth
3 in
76 mm
Weight 1
40 lb
18 kg
Note
Custom sizes are available.
1 Weight is based on actual part number.
4/20/2014 | Page 2 of 2
