Magnetic Products 400 Series, Plate Magnets User Manual
Page 2
Advertising
Overall Length "A"
12.5 in
316 mm
Magnetic Face Length "B"
10.5 in
267 mm
Thickness "C"
2.750 in
70 mm
Step Height "D"
1.000 in
25 mm
Effective Magnetic Field Depth
5 in
127 mm
Weight 1
60 lb
27 kg
Note
Custom sizes are available.
1 Weight is based on actual part number.
