Magnetic Products 500 Series, Plate Magnets User Manual
Page 2
Advertising
Overall Length "A"
15.5 in
394 mm
Magnetic Face Length "B"
13.5 in
343 mm
Thickness "C"
4.250 in
108 mm
Step Height "D"
1.500 in
38 mm
Effective Magnetic Field Depth
8 in
203 mm
Weight 1
95 lb
43 kg
Note
Custom sizes are available.
1 Weight is based on actual part number.
4/20/2014 | Page 2 of 2
