Magnetic Products MH-600 - Manual (Page 2)

Diagram
Magnetic Hump Separators (MH Series) Diagram
Plate Magnet Series
600
Spout Size "A"
10 in
254 mm
Flange Length "B"
16.25 in
413 mm
Approx. Overall Height "C"
52 in
1321 mm
Effective Magnetic Field Depth
10 in
279 mm
Weight
486 lb
220 kg
4/20/2014 | Page 2 of 2
