Diagram
Box Rails (BR Series) Diagram
Width Dim. "A"
4.187 in
106 mm
Thickness "B"
1.937 in
49 mm
Length Dim. "C"
Built to Customer's Specification (Up to 8')
Tap Distance Dim. "D"
Built to Customer's Specifications (12" On-Center in Backplate Standard)
