DE DIETRICH DRC629JE - Manual (Page 13)

38
PR01
540
50
3
2 1
Building-in instructions
Dimensions of housing
Height (1) 1780 mm
Depth (2) 550 mm
Width (3) 560 mm
For safety reasons, minimum ventilation must be as
shown in Fig.
Attention: keep ventilation openings clear of
obstruction.
It is necessary that the niche is provided with a
conduct of ventilation having the following
dimensions:
Depth 50 mm
Width 540 mm
50 mm
min.
200 cm 2
200 cm 2
min.
D567
