MegaRAID SATA 300 Storage Adapters User’s Guide v
Version 1.4 Copyright © 2004–2006 by LSI Logic Corporation. All rights reserved.
Preface
This book is the user’s guide for the LSI Logic MegaRAID
®
Serial ATA
(SATA) 300 family of storage adapters. It contains complete physical
installation instructions, as well as physical and electrical specifications
for the SATA 300 PCI-X and PCI Express storage adapters.
The MegaRAID SATA 300 storage adapter family consists of the
following products:
•
The MegaRAID SATA 300-4XLP PCI-X (low profile) storage adapter
•
The MegaRAID SATA 300-4ELP PCI Express (low profile) storage
adapter
•
The MegaRAID SATA 300-8X PCI-X storage adapter
•
The MegaRAID SATA 300-8XLP PCI-X (low profile) storage adapter
•
The MegaRAID SATA 300-8ELP PCI Express (low profile) storage
adapter
For details on how to configure the storage adapters, and for an overview
of the software drivers, see the MegaRAID Configuration Software
User’s Guide.
Audience
This document assumes that you have some familiarity with RAID
controllers and related support devices. The people who benefit from this
book are:
•
Anyone installing a SATA 300 PCI-X or PCI Express storage adapter
into a system
•
Engineers who are designing a SATA 300 PCI-X or PCI Express
storage adapter into a system
