7 Ethernet LED Indicators
Troubleshooting the operation of the Ethernet port can be performed using
several methods.
The first and quickest is to scan the LEDs on the module to determine the
existence and possibly the cause of a problem. This section provides insight into
the operation of the Ethernet Port's status LEDs. Details on the module's other
LEDs can be found in the product User Manual.
LED Color Description
Off No activity on the port. Data
Green
Flash The port is either actively transmitting or
receiving data
Off No connection to hub or network is detected Link
Green Solid Connected to hub or network correctly
