Philips BT7202/13 - Manual (Page 2)

Electromagnetic fields (EMF)
- This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic fields.
General
- The appliance is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Display
Battery status indications
- When the battery is almost empty, the battery
charge indicator flashes orange (Fig. 3).
- When the appliance is charging, the battery
charge indicator flashes white (Fig. 4).
- When the battery is fully charged, the battery
charge indicator lights up white continuously
(Fig. 5).
Note: The lights switch off automatically after
30 minutes.
Hair length indications
The selected hair length setting will show above
the zoom wheel when you select the desired
length setting with the zoom
wheel (Fig. 6).
Charging
Charging takes approx. 1 hour. Charge the
appliance before you use it for the first time and
when the display indicates that the battery is
almost empty.
1 Make sure the appliance is switched off.
2 Put the adapter in the wall socket and put the
small plug in the appliance (Fig. 7).
3 After charging, remove the adapter from the
wall socket and pull the small plug out of the
appliance.
When the appliance is fully charged, it has a
cordless operating time of up to 60 minutes.
Using the appliance
Note: This appliance can be used without cord or
directly from the power outlet.
You can use this appliance for a stubble and
a short beard. This appliance has an integrated
vacuum system that catches cut beard hair for
a less mess trimming experience.
The vacuum system is activated automatically as
soon as you switch on the appliance.
Note: Switch off and clean the appliance after
each use.
Switching the appliance on and off
Press the on/off button once to switch the
appliance on or
off (Fig. 8).
Trimming without comb
- You can use the appliance without beard and
stubble comb to trim hair close to the skin or
to contour the neckline and sideburns. To trim
hair close to the skin, place the flat side of the
trimming head against your skin and make
strokes in the desired
direction (Fig. 9).
- You can use the precision trimmer to create
fine lines and contours around your facial style,
close to the
skin (Fig. 10). Simply pull the cutting
element straight off (Fig. 11) and insert the
precisi on trimmer (Fig. 12).
- For contouring hold the trimming head
perpendicular to the skin and move the
trimming head upwards or downwards with
gentle
pressure (Fig. 13).
Trimming with comb
You can use the beard and stubble comb attached
to the cutting element to groom your beard and
moustache in your preferred style. You can choose
from 20 length settings ranging from 0.5mm to
10mm in steps of 0.5mm.
1 Attach the comb onto the
appliance (Fig. 14).
2 Turn the zoom wheel to select the desired
length setting (Fig. 6).
Note: When you trim for the first time, start at
the highest length setting to familiarise yourself
with the appliance.
3 Switch on the appliance.
4 To trim most effectively, move the appliance
against the hair growth direction. Make sure that
the surface of the comb always stays in contact
with the
skin (Fig. 15).
Cleaning and maintenance
Cleaning the appliance
Note: Only the cutting element and the comb can
be cleaned with water.
We advise you to empty the hair-collection
chamber after each trimming session. When you
trim long, dense beards, it may also be necessary
to empty the hair-collection chamber during the
trimming session in order to maintain optimal
suction performance.
1 Switch off the appliance and disconnect it from
the power outlet.
2 Wipe the housing of the appliance with a dry
cloth.
3 Remove the
comb (Fig. 16) and clean it with the
cleaning brush and/or rinse it under the tap
(Fig. 17).
4 Remove the cutting element and clean it under
the tap (Fig. 18). Shake off excess water and
leave to dry completely.
Caution: Never dry the cutting element with a towel
or tissue, as this may damage the trimming teeth.
5 Shake and/or brush out the hairs that have
collected in the hair chamber (Fig. 19, Fig. 20).
6 After cleaning, reattach the cutting element
(Fig. 21) and comb (Fig. 14) to the appliance.
Recycling
- This symbol means that this product shall not
be disposed of with normal household waste
(2012/19/EU).
- This symbol means that this product contains
a built-in rechargeable battery which shall not
be disposed of with
normal household waste
(2006/66/EC). We strongly advise you to take
your product to an official collection point or
a Philips service centre to have a professional
remove the rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Warranty and support
If you need information or support, please
visit
www.philips.com/support or read the
international warranty leaflet.
PORTUGUÊS DO BRASIL
Descrição geral (Fig. 1)
1 Lâmina de corte
2 Sistema a vácuo
3 Ajustes de comprimento
4 Controle giratório
5 Botão liga/desliga
6 Indicador de status da bateria
7 Esponja de limpeza
8 Escova de limpeza
9 Plugue pequeno
10 Fonte de alimentação (adaptador)
11 Aparador de precisão
12 Pente para barba e barba por fazer
Nota: Os acessórios fornecidos podem variar para
produtos diferentes. A caixa mostra os acessórios
que foram fornecidos com seu aparelho.
Informações importantes de
segurança
Leia atentamente estas informações importantes
antes de usar o aparelho e seus acessórios.
Guarde-as para futuras consultas. Os acessórios
fornecidos podem variar para produtos diferentes.
Perigo
- Mantenha a fonte de
alimentação seca (fig. 2).
Aviso
- A fonte de alimentação
contém um transformador.
Não desligue a fonte de
alimentação para trocá-
la por outro conector, pois
isso causará uma situação
perigosa.
- Carregue o aparelho somente
com a fonte de alimentação
fornecida (HQ8505).
- Este aparelho não deve ser
usado por pessoas (inclusive
crianças) com capacidades
físicas, mentais ou sensoriais
reduzidas ou com pouca
experiência e conhecimento,
a menos que sejam
supervisionadas ou instruídas
sobre o uso do aparelho por
uma pessoa responsável por
sua segurança.
- Crianças devem ser
supervisionadas para que não
brinquem com o aparelho.
- Sempre verifique o aparelho
antes de usá-lo. Não use
o aparelho se ele estiver
danificado, pois isso pode
causar ferimentos. Sempre
substitua uma peça danificada
por outra do tipo original.
- Não abra o aparelho para
trocar a bateria recarregável.
Atenção
- Este aparelho nгo й
lavável. Nunca mergulhe-o
na água nem lave-o em água
corrente (fig. 2).
- Só use este aparelho para
o propósito ao qual ele se
destina, conforme mostrado
no manual do usuário.
