Samsung U32J590 31.5" 16:9 4K UHD LCD Monitor - Manual (Page 37)

37
PC/AV Mode
Set PC/AV Mode to AV . The picture size will be enlarged.
This option is useful when you view a movie.
• Set to PC when connected to a PC.
• Set to AV when connected to an AV device.
―
Supplied for the wide models only such as 16:9 or 16:10.
―
If the monitor (when set to HDMI1 , HDMI2 , DisplayPort ) is in power saving mode or is displaying the
message Check Signal Cable , press the icon to display the On Screen Display (OSD). You can select PC
or AV .
DisplayPort Ver.
Select your Displayport.
―
Incorrect settings may cause the screen to go blank. If this occurs, check the device specifications.
―
If the monitor (when set to HDMI1 , HDMI2 , DisplayPort ) is in power saving mode or is displaying the
message Check Signal Cable , press the icon to display the On Screen Display (OSD). You can select 1.1
or 1.2↑ .
―
If you select 1.1 , the maximum resolution of your screen drops to 2560 x 1440 due to the limitations in HBR1
transmission speeds.
Source Detection
Select either Auto or Manual as the method to recognize input signal.
―
Not available when PIP/PBP Mode is set to On .
Key Repeat Time
Control the response rate of a button when the button is pressed.
Acceleration , 1 sec , or 2 sec can be selected. If No Repeat is selected, a command responds only once
when a button is pressed.
Power LED On
Configure the settings to enable or disable the power LED located at the lower part of the product.
• Working : The power LED is on when the product is turned on.
• Stand-by : The power LED is on when the product is turned off.
Reset All
Return all the settings for the product to the default factory settings.
