Roland GK-3B - Divided Bass Pickup - Manual (Page 15)

15
Attaching the GK-3B to the Bass
Mounting on the Front of the Bass
1. Remove three screws from the
underside of the controller, then attach
the GK-3B to holder “A.”
fig.1200e (Attaching to the Holder)
* Holder A has six screw holes. Refer to the figure to
ensure the holder is attached correctly.
2. Attach holder “B” so that the bass
body is sandwiched between the two
holders.
* Make sure that Holder A is firmly pressed against
the side surface of the bass body.
fig.1210e (Attaching to the Bass 2)
3. Tighten holders “A” and “B” using the
screw (5 x 20 mm).
fig.1220e (Spacer LP)
GK-3B
Holder A
Holder B
Holder A
Screw
5 x 20 mm
Holder B
Holder A
Screw
5 x 20 mm
