57
Menu List
Menu item
Value
(Bold: default)
Explanation
EQUALIZER
OFF
, ON
Turns the equalizer on/off.
Effect Adjusts the tone for each frequency band.
Hi GAIN
-15.0–
0.0
–15.0dB
Boosts or attenuates the high band.
Hi FREQUENCY
1.0–
10.0
–20.0kHz
Specifies the center frequency when changing the tone in the high band.
Mid GAIN
-15.0–
0.0
–15.0dB
Boosts or attenuates the middle band.
Mid FREQUENCY
20.0–
500Hz
–20.0kHz
Specifies the center frequency when changing the tone in the middle band.
Mid Q
0.5–
1.0
–16.0
Adjusts the width of the frequency band when boosting or attenuating the
middle band.
Lo GAIN
-15.0–
0.0
–15.0dB
Boosts or attenuates the low band.
Lo FREQUENCY
20.0–
500Hz
–20.0kHz
Specifies the center frequency when changing the tone in the low band.
