DE60x Headset Microphone
Specifications
Element
Back electret condenser
Capsule Dimension
7.35mm
Polar pattern
Cardioid (Unidirectional)
Frequency Response
50Hz–18KHz
Sensitivity
-45dB 1V/Pa ±3dB at1kHz
Output impedance
2kΩ ±30%
SPL max
135 dB
Operating voltage
0.8–5V DC
Cable
4x ø1.4mm*1.2m
Weight 13g
Headset Dimensions (LxDxH)
5.3” x 4” x 2.7” / 135mm x 101.2mm x 68.2mm
Included Adapter Cables
1/8” (3.5mm), Hirose
®
4-Pin, Switchcraft
®
TA3F,
Switchcraft
®
TA4F
Accessories
(4) Windscreens, Clothing Collar Clip, Carry Case
At Samson, we are continually improving our products, therefore specifications and images are
subject to change without notice.
