Technical Specifications
Warranty 2 Years
Adapter Style Adapter
Audio
Yes
Chipset ID CH7101A-BF
QFN 40PIN SMD
Converter
Type Format Converter
Output Signal VGA
Ports
1
Audio
Specifications 2-channel stereo (3.5mm)
Maximum
Digital
Resolutions 1900x1200 @ 60Hz
Supported
Resolutions Widescreen(16/32 bit):
1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900, 1360x768, 1280x800, 1280x768,
1280x720
Standard(16/32 bit):
1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x864, 1024x768, 800x600
Wide Screen
Supported Yes
Connector A 1 - HDMI (19 pin) Male Input
Connector B 1 - VGA (15 pin; High Density D-Sub) Female Output
Connector B 1 - 3.5 mm Mini-Jack (3 Position) Female Output
Note This converter is not compatible with Mac computers that use Intel HD 4000 cards (Mac Mini), for
specific support for these devices StarTech.com offers the [%product id="MCHD2VGA"
text="Mac Mini to VGA adapter"%] (MCHD2VGA)
This converter will not output digitally encrypted content
Humidity 90% RH
Operating
Temperature 10°C to 40°C (50°F to 104°F)
Storage
Temperature -20°C to 70°C (-4°F to 158°F)
Shipping
(Package) 0.8 oz [23 g]
