StarTech.com Mini DisplayPort Male to Dual DisplayPort Female MST Hub (USB Powered) - Manual (Page 4)

Technical Specifications
Warranty 2 Years
Audio Yes
Chipset ID STDP4320
Converter
Type MST Hub
Output
Signal DisplayPort
Ports 2
Maximum
Digital
Resolutions 3840x2160 @ 30hz
Supported
Resolutions Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the
available bandwidth with the remaining ports, please see our guideline below for determining an
ideal resolution for your setup.
Average resolution bandwidth allocation
1920x1080 (High-definition 1080p) @60hz - 22%
1920x1200 @60hz - 30%
2560x1440 @60hz - 35%
2560x1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen
Supported Yes
Connector A 1 - Mini-DisplayPort (20 pin) Male Input
Connector B 2 - DisplayPort (20 pin) Female Output
OS
Compatibility
Windows 10 (32/64)
Windows 8/8.1 (32/64)
Windows 7(32/64)
Note DisplayPort 1.2 with MST+HBR2 support from the GPU is required for independent display output
Note When using a DisplayPort 1.1 video card the MSTMDP122DP will act as splitter, automatically
mirroring your video source across all displays. Resolution limitations apply
Power
Source USB-Powered
Humidity 50-90%
