Technical Specifications
Warranty 2 Years
Audio Yes
Cabling Coaxial
Chipset ID Gennum
Daisy-Chain Yes
Output Signal HDMI
Ports 1
Rack-Mountable Yes
Connector A 2 - SDI (BNC) Receptacle
Connector B 1 - HDMI (19 pin) Female
Audio Specifications 8 Channel Digital Audio @ 48 kHz
Max Distance 230 m / 755 ft
Maximum Cable Length 754.4 ft [230 m]
Maximum Data Transfer Rate 1.485 Gbps
Maximum Digital Resolutions 1080p
Supported Resolutions 1920x1080 (1080p) @ 24, 25, 30, 50 & 60 FPS
1920x1080 (1080i) @ 50 & 60 FPS
1280x720 (720p) @ 24, 25, 30, 50 & 60 FPS
Supports 525i & 625i SD D1 format
Supports 8-bit or 10-bit component digital
video
RGB or YCbCr 4:4:4 sampled
YCbCr 4:2:2 or 4:2:0 sampled
Wide Screen Supported Yes
Color Black
Product Height 1 in [25 mm]
Product Length 3.9 in [100 mm]
Product Weight 7.1 oz [202 g]
Product Width 2.8 in [70 mm]
Center Tip Polarity Positive
Input Current 0.5 A
Input Voltage 100 ~ 240 AC
Output Current 2 A
Output Voltage 5 DC
Plug Type M
Humidity 5% to 90 % RH (no condensation)
Operating Temperature 0°C to 40°C (32°F to 158°F)
Storage Temperature -10°C to 60°C (14°F to 176°F)
Shipping (Package) Weight 0 lb [0 kg]
Included in Package 1 - SDI to HDMI Adapter
