Technical Specifications
Warranty
2 Years
Interface
Serial
Port Style
External Hub
Ports
1
Bus Type
USB 2.0
Chipset ID
FTDI - FT232RL
Connector Type(s)
1 - USB B (4 pin) Female
External Ports
1 - DB-9 (9 pin; D-Sub) Male
External Ports
1 - Terminal Block (5 Wire)
Serial Protocol
RS-422/485
Max Baud Rate
921.6 Kbps
Data Bits
7, 8
FIFO
256 Bytes
Parity
Even, Odd, Mark, Space, None
Stop Bits
1, 2
Isolation
2500 Vrms
Surge Protection
500W
OS Compatibility
Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), XP Embedded, CE 6.0/5.0/4.2,
2000, ME, 98SE, 95, DOS
Windows® Server 2008 R2, 2003(32/64)
Mac OS 8.x, 9.x, 10.x (Tested up to 10.8)
Linux
Cable Length
1.8 m [6 ft]
Color
Black
Enclosure Type
Steel
Product Length
118 mm [4.6 in]
Product Width
64 mm [2.5 in]
Product Height
23 mm [0.9 in]
Product Weight
180 g [6.4 oz]
Power Adapter
Included
USB Powered
Input Voltage
5 DC
Input Current
200mA
Humidity
5~95% RH
Operating
0°C to 55°C (32°F to 131°F)
