Acer VT270 bmizx 27" 10-Point Touchscreen Monitor - Manual (Page 25)

English
System
Mode - Standard
VGA IN Input
On
Quick Start Mode
Wide Mode
Hot Key Assignment
DDC/CI
Normal
Auto Source
Off
Power-off
USB Charge
Off
HDMI Black Level
On
Full
Color
Performance
Informa�on
Audio
OSD
System
1. Press the MENU key to open the OSD.
2. Press up or down button to select System from the OSD. Then press enter button to
enter it.
3. Toggle to the left or right to control functions.
4.
Input: Select the source from VGA IN, HDMI.
5. Auto Source: The default is “On”, which can support auto search for signal source in
order.
Note: Surround application must set Auto Source is “Off”.
6. Wide mode: You can select which screen aspect you are using. The options are Aspect
and Full.
7. Hot Key Assigment: Select the function of shortcut key 1(Auto Config (Only VGA),
Modes, Brightness, Volume (Only Audio Model), Gamma, Contrast, Blue Light, Over
Drive) and shortcut keys 2 (Modes, Brightness, Volume (Only Audio Model), Gamma,
Contrast, Blue Light, Over Drive, Auto Config (Only VGA)).
8. DDC/CI: Allows the monitor settings to be set through the software on the PC.
-----------------------------------------------------------------------------------------------------------
Note: DDC/CI, short for Display Data Channel/Command Interface, which allows
monitor controls to be sent via software.
9. HDMI Black level: Select to set HDMI black level.
10. Quick start mode: Select Off or On. Turn on to speed up boot speed.
11. Power-off USB charge: Turn On or Off. On: DC off/Saving mode can to electrify for
USB port. Off: DC off/Saving mode can't to electrify for USB port.
