CHAPTER 3: ON SCREEN DISPLAY MENU

18

3.1 Using the OSD Menu

1. Press the MENU button to call out the OSD window.

Submenu

1920x1080 60Hz

Contrast

78

Brightness

Color Temp.

Auto Adjust

Color Adjust

90

Menu

option

During HDMI/DisplayPort input,

Picture Setting

is disabled and

grey out.

2. Press the

t

or

u

button to select a menu and press the MENU button to enter the selected

menu.

1920x1080 60Hz

H. Position

50

V. Position

Clock

Phase

50

50

78

1920x1080 60Hz

H. Position

V. Position

Clock

Phase

50

50

50

78

A selected menu is highlighted in grey and the text of the selected menu option turns yellow.

3. Press the

t

or

u

button to select an option and press the MENU button to enter its

submenu.

1920x1080 60Hz

H. Position

V. Position

Clock

Phase

50

50

50

78

1920x1080 60Hz

H. Position

V. Position

Clock

Phase

50

50

50

78

The text of the selected menu option or submenu turns yellow.

4. Press the

t

or

u

button to adjust the settings.

5. To exit the submenu, press the AUTO button.
6. To close the OSD window, press the AUTO button twice.

Note:

When settings are modified, all changes are saved when the user does the following:

• Proceeds to another menu
• Exits the OSD menu
• Waits for the OSD menu to disappear

Chapter 3: On Screen Display Menu
