Specification
General Specification
Panel
Model name AG493UCX2
Driving system TFT Color LCD
Viewable Image Size 124 cm diagonal
Pixel pitch 0.2331mm(H) x 0.2331mm(V)
Video HDMI /DP/USB C
Display Color 16.7M Colors
Others
Horizontal scan range
30k-200kHz (HDMI)
30k-250kHz (DP/USB C)
Horizontal scan Size(Maximum) 1191.936mm
Vertical scan range
48-75Hz (HDMI)
48-120Hz (USB C)
48-165Hz (DP)
Vertical Scan Size(Maximum) 335.232mm
Optimal preset resolution 5120x1440@60Hz
Max resolution
5120x1440@75Hz (HDMI)
5120x1440@120Hz (USB C*)
5120x1440@165Hz (DP)
Plug & Play VESA DDC2B/CI
Connector HDMIx3, DP,USB C(DP Alt), USBx3, USB Up, Earphone out
Power Source 100-240V~, 50/60Hz, 3A
Power Consumption
Typical(default brightness and contrast) 68 W
Max. (brightness = 100, contrast =100) ≤245W
Standby mode ≤ 0.5 W
USB C
USB C Reversible plug connector
Super speed Data and Video transfer
DP Built-in DisplayPort Alt mode
Power Delivery USB PD version 3.0
Max power delivery Up to 65W (5V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
*:When the USB C(DP Alt) is set to USB2.0 or off, the max resolution of USB C interface is 5120x1440@120Hz.
