Page 18
3-2
Chapter 3: General Instructions
3.1.2
OSD function introduction
1.
Gaming
EXIT
Back
Enter
VG32AQA1A
60Hz
2560x1440
ASUS TUF GAMING
GameVisual
Racing Mode
Input Select
DisplayPort 1
HDR
ASUS Gaming HDR
Overclocking
Variable OD
AMD FreeSync Premium
ELMB
GamePlus
GameVisual
Shadow Boost
Gaming
Color
Input Select
MyFavorite
•
Overclocking
:
*
ON
: This function allows you to adjust the refresh rate.
*
Max Refresh Rate
: Allows you to select a maximum refresh rate
of 170Hz (Only for DisplayPort input). After selecting, press the
( ) button to activate the setting.
Overclocking may cause screen flickering. To reduce such effects, disconnect
the DisplayPort cable and use the monitor OSD menu to try again with a safer
Max. Refresh rate.
•
Variable OD
: Improves the gray level response time of the LCD panel.
The adjusting range is from Level 0 to Level 5.
This function is not available when
ELMB
is enabled.
•
AMD FreeSync Premium:
Allows an Adaptive-Sync supported* graphics
source to dynamically adjust display refresh rate based on typical content
frame rates for power efficient, virtually stutter free and low-latency
display update.
•
AMD FreeSync Premium
can only be activated within 48Hz~144Hz for
HDMI and 48Hz~170Hz for DisplayPort.
•
For supported GPUs, minimum PC system and driver requirements,
please contact the GPU manufactures.
•
ELMB
:
ELMB
can only be activated when
AMD FreeSync Premium
is
Off
and the refresh rate is 120Hz, 144Hz, 155Hz, 160Hz, 165Hz or
170Hz. This function eliminates screen tearing, reduces ghosting and
motion blur when playing games. The function includes 3-level clarity and
position adjustment.
