LG 27ML600M-B 27" 16:9 Radeon FreeSync IPS Monitor - Manual (Page 18)

18
ENGLISH
Color Adjust
Gamma
Mode 1, Mode 2,
Mode 3
The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the
lighter the image becomes.
Mode 4 If you do not need to adjust the gamma settings, select Mode 4.
Color Temp
Selects the factory default picture color.
Warm: Sets the screen color to a reddish tone.
Medium: Sets the screen color between a red and blue tone.
Cool: Sets the screen color to a bluish tone.
Custom: The user can adjust it to red, green or blue by customization.
Red
You can customize the picture color using Red, Green, and Blue colors. Green
Blue
Configuration Adjust
(D-SUB only)
Horizontal To move image left and right.
Vertical To move image up and down.
Clock To minimize any vertical bars or stripes visible on the screen background.The horizontal screen size will also change.
Phase To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters.
Resolution
(D-SUB only)
User can set the desired resolution.This option is enabled only when the screen resolution on your computer is set to the following(D-SUB only).
NOTE
• The function is enabled only when the screen resolution on your computer is set to the following, except that the PC output wrong resolution.
1024x768, 1280x768, 1360x768, 1366x768,Off
1280x960, 1600x900,Off
1440x900, 1600x900,Off
Picture Reset Do you want to reset your settings?
No Cancel the select.
Yes Returns to the default settings.
