2. Setting up the monitor
Description of the On Screen Display
What is On-Screen Display (OSD)?
On-Screen Display (OSD) is a feature in
all Philips LCD monitors. It allows an end
user to adjust screen performance or
select functions of the monitors directly
through an on-screen instruction
window. A user friendly on screen
display interface is shown as below:
2X3V7QS
2X3V7QH, 2X3V7QD, 2X3V7QJ
Basic and simple instruction on the
control keys
In the OSD shown above, you can press
buttons at the front bezel of the
monitor to move the cursor, and press
OK
button to confirm the choice or
change.
The OSD Menu
Below is an overall view of the structure
of the On-Screen Display. You can use
this as a reference when you want to
work your way around the different
adjustments later on.
Main menu
Sub menu
OSD Settings
Setup
Language
Color
Input
Picture Format
Brightness
Contrast
Horizontal
Vertical
Transparency
OSD Time Out
H.Position
Auto
V.Position
Phase
Clock
Resolution Notification
Reset
Information
English, Deutsch, Español,
Ελληνική,
Français,
Italiano, Magyar
，
Nederlands, Português,
Português do Brasil
，
Polski
，
Русский
,Svenska
，
Suomi
，
Türkçe
，
Č
eština
，
Українська
,
简体中文
,
繁
體
中文，日本
語，
한국어
Color Temperature
sRGB
User Define
VGA
DVI (2X3V7QS, 2X3V7QD)
(available for selected models)
HDMI (2X3V7QH, 2X3V7QD)
HDMI 1.4 (2X3V7QJ)
DisplayPort (2X3V7QJ)
SmartResponse
(2X3V7QH, 2X3V7QD, 2X3V7QJ)
SmartContrast
Gamma
Over Scan
(2X3V7QH, 2X3V7QD, 2X3V7QJ)
Pixel Orbiting
Wide Screen, 4:3
0~100
0~100
Sharpness
0~100
0~100
0~100
Off, 1, 2, 3, 4
5s, 10s, 20s, 30s, 60s
0~100
On, Off
Yes, No
0~100
0~100
0~100
Native(2X3V7QJA),
6500K, 7500K, 9300K
Red: 0~100
Green: 0~100
Blue: 0~100
Off, Fast, Faster, Fastest
On, Off
1.8, 2.0, 2.2, 2.4, 2.6
On, Off
On, Off
LowBlue Mode
On
Off
1, 2, 3
Audio
(2X3V7QH/
2X3V7QD/
2X3V7QJ)
Audio In,
HDMI,
DisplayPort(2X3V7QJA)
Stand-Alone
(2X3V7QHA/2X3V7QDA/2X3V7QJA)
0~100
On, Off
On, Off
Volume
(2X3V7QH/2X3V7QD/2X3V7QJ)
Audio Source
(2X3V7QHA/
2X3V7QDA/
2X3V7QJA)
Mute
(2X3V7QH/2X3V7QD/2X3V7QJ)
