Owner’s Manual
MTest-1 Cable Tester Specifications
Appendix B: Technical Information
Physical Properties
Height 2.7 in / 69 mm
Width 6.5 in / 165 mm
Depth 4.8 in / 122 mm
Weight 1.4 lb / 0.6 kg
Disclaimer
Since we are always striving to make our products better by incorporating new
and improved materials, components, and manufacturing methods, we reserve
the right to change these specifications at any time without notice.
The “Running Man” figure is a registered trademark of LOUD Audio, LLC.
All other brand names mentioned are trademarks or registered trademarks
of their respective holders, and are hereby acknowledged.
©2018 LOUD Audio, LLC
All Rights Reserved.
Input / Output
Input / Output Type 1/4" TRS / TS Female Bal – Unbal
1/8" TRS / TS Female Bal – Unbal
XLR Female Bal – Unbal
XLR Male Bal – Unbal
RCA / Phono Female Bal – Unbal
Speakon Female Bal – Unbal
MIDI Female Bal – Unbal
Banana / Continuity Female Bal – Unbal
Power Requirements
Internal 9V Battery
Display LEDs
Banana / Continuity,
Ground, Battery Check,
Pin verification
WEIGHT
1.4 lb
0.6 kg
4.8 in / 122 mm
6.5 in
165 mm
2.7 in
69 mm
MTest-1 Cable Tester Dimensions
