MOVE'N SEE Pix4Team 2 Auto-Follow Camera - Manual (Page 19)

F. Technical specifications
Be careful not to scratch or damage the lens of the robot's wide-angle camera. Always replace the cover after use and clean
the lens from time to time with a microfiber cloth.
Be careful, when using the robot as the robot's heatsink can reach 60 degrees.
Note that the recording quality of the video from the SONY/CANON (or other brand) camera recorded in the robot micro-SD
card will be 1080p max. If you camera can have 4K and if you need 4K, it has to be recorded on the micro-SD card which is in
your camera.
Masts, tripods, cameras / smartphones / tablets must be purchased separately.
Usage
Indoor & outdoor use.
Must be placed on the side of a playing field.
Installation height: approx. 4.80 meters (16 ft) or more above the field.
Covers field over 100 x 100 meters wide (330 x 330 ft).
Allows you to film on reduced fields of: Soccer, American Football, Basketball, Volleyball, Handball, Ice Hockey and Lacrosse.
Power supply
Can be plugged into the main socket outlet with a 19V DC (provided).
Can be powered by a Li-Ion battery NP-F970 (6600 mAh, 48.8Wh) and compatible batteries (not provided). Autonomy with a
NP-F970 battery: 2h30-3h30.
Compatible Cameras & Smartphone - tablet
Camera
Over 100 SONY and CANON compatible cameras (see the complet list https://shop.movensee.com/en/content/33-
compatible-devices-with-pix4team#cameras)
Smartphone - tablet
Compatible with Android 5 and newer smartphones & tablets equipped with Bluetooth 4 and newer.
Compatible with iPad Air and newer & iPhone 5s and newer
Connectivity
Prise jack DC pour l'alimentation électrique (19V).
Prise jack Ø3.5 permettant de piloter le ZOOM et le REC des caméras externes.
Prise HDMI (entrée) pour recevoir la vidéo de la caméra externe.
Prise RJ45 (éthernet).
Embase microSD pour le stockage des vidéos.
Mechanical
Size
26 H x 13 L x 13 W (cm)
10.2 H x 5.1 L x 5.1 W (in)
Weight
1.4 kg (3.1 lb)
Max Camera Weight
1.5 kg (3.3 lb)
Max rotation speed
PAN: 120°/s
TILT: 40°/s
Stand & Tripod
You need a tripod or a stand with a 3/8" screw.
We do not recommend the use of tripods fitted with ball joints. The stability of these tripods is generally quite poor (except for
19
