65BDL3550Q
47
Schedule
Schedule list
Enable
Start time
End time
Input
Playlist
Days of the week
Every week
1
Back SAVE
• {Schedule list} – Select 1-7 schedules to edit.
• {Enable} – Enable/disable selected schedule. If time
conflict with other schedule or start/end time, input
source are empty, user cannot enable this schedule.
• {Start time} – Set start time.
• {End time} – Set end time.
• {Input} – Set input source, system will go to selected
source automatically at start time.
• {Play list} – Set playlist 1-7 for MediaPlayer, PDF Player
and Browser sources.
• {Days of the week} – Set Sunday, Monday, Tuesday,
Wednesday, Thursday, Friday and Saturday.
• {Every week} – Set lifecycle.
• {Back} – Cancel and do not change schedule data.
• {SAVE} – Save schedule data.
HDMI with One Wire
Enable or disable HDMI CEC.
HDMI One Wire Power Off
Allow user to set multiple devices to standby mode by
pressing the power button. This function is only available
when HDMI CEC is enabled.
Language
Select the language used in the OSD menu.
The options are: English/Deutsch/
简体中文 /Français/
Italiano/Español/ Pyccкий /Polski/Türkçe/ 繁體中文 / 日本語
/Português/ العربية /Danish/Swedish/Finnish/Norwegian/
Dutch/Czech/Lithuanian/Latvian/Estonian.
OSD Transparency
Adjust OSD transparency.
• {Off} - Transparency off.
• {1-100} - Transparency level 1-100
Power Save
Mode 1 [TCP off, WOL on, auto off]
Mode 2 [TCP off, WOL on, auto on/off]
Mode 3 [TCP on, WOL off, auto on/off]
Mode 4 [TCP on, WOL off, no auto on/off]
Power
Save
RCU Power
Button Off
No Signal WOL Android
(ARM)
Mode 1 DC OFF DC OFF V ARM off
Mode 2 DC OFF when signal is back,
system wake up
V ARM off
Mode 3 Backlight
OFF
when signal is back,
system wake up
X ARM on
Mode 4 Backlight
OFF
Backlight always on,
show no signal
X ARM on
Following table is the action for Android board with
different power mode.
Power mode Mode 1, Mode 2 Mode 3, Mode 4
DC off System shutdown 1. Media Player, Browser, PDF
Player and SmartCMS will
close.
2. Android system goes to
default black launcher.
DC on System boot up Android system reboot. If
Logo settings is off, system
directly turn backlight on
without rebooting.
Advanced option reset
Reset all settings except {Date and Time} in the advanced
option menu to factory preset values.
