Blackmagic Design ATEM Television Studio Pro 4K Live Production Switcher - Manual

Connections
Total Video Inputs
8
Total Outputs
12
Total Aux Outputs
1
SDI Rates
1.5G, 3G, 6G, 12G.
Total Audio Inputs
2 x XLR. 1 x Microphone.
Total Audio Outputs
1 x Headphone.
SDI Video Inputs
8 x 10-bit HD/UHD switchable. 2
channel embedded audio.
HDMI Video Inputs
None
Reference Inputs
Tri-Sync or Black Burst.
Video Input Re ‑ Sync
On all 8 inputs.
Frame rate and format convertors
On all 8 inputs.
SDI Program Outputs
9 x 10-bit HD/UHD switchable.
SDI Audio Outputs
2 Ch embedded into SDI output.
Total Multi Views
1
SDI Multi View Outputs
1
HDMI Multi View Outputs
1
ATEM Television Studio
Pro 4K
ATEM Television Studio Pro 4K features 8 independent 12G-SDI inputs, for working
in all popular HD and Ultra HD formats up to 2160p60. Each input features re-sync
as well as a full low latency standards converter, which means the input is
automatically adapted to the switchers format. You can even have 8 inputs, all
running different video formats! The upgraded Fairlight audio mixer features
dynamics, 6 band parametric EQ, dual mono channel split and stereo simulator
with audio delay on the analog inputs. ATEM Television Studio Pro 4K also features
the ATEM Advanced Chroma Key, Ultra HD multi
‑ view and motion clips in the
media pool.
$2,995
Product Technical Specifications
ATEM Television Studio Pro 4K - Technical Specifications Page 1 of 5
