QSC Audio AC-C6T AcousticCoverage Series 6" 2-Way 30W Ceiling Loudspeaker (Pair, White) - Manual

Wide Area Paging ∙ Background Music ∙ Office Buildings ∙ Healthcare Facilities ∙
Concourses ∙ Transportation Terminals ∙ Ancillary Support in Larger Systems
AC-C6T
Features
• High quality transducers provide
exceptional clarity through the
critical voice range.
• Improved musicality often not seen
in typical BGM class products.
• Ported baffle for increased low
frequency extension down to 65 Hz.
• Low saturation 70/100V
transformers with 8 ohm bypass.
• 4-pole Euroblock connector eases
system wiring.
• Advanced voicing via QSC Intrinsic
Correction™, applied using Q-Sys
processing or CXD amplifier
platforms.
• White (RAL 9010) with
UV inhibitors to match
complimenting QSC product
families.
• Complete EASE, CF2, CAD, & BIM
information available online
The QSC AcousticCoverage™ AC-C6T is a
ceiling-mounted 6” two-way loudspeaker
with 70/100V transformer, suitable for a wide
variety of voice paging and background
music sound reinforcement applications.
AcousticCoverage™ is designed to offer
integrators a cost-effective solution for
applications where voice reinforced coverage
is of primary concern, while providing
improved musicality often not seen in
typical BGM class products.
The high quality 6-inch polypropylene cone
transducer with butyl rubber surround and
the sensitivity matched coaxially mounted
.86-inch silk dome tweeter offers pristine
clarity through the critical vocal range for
increased speech intelligibilty. With 110
degrees of conical coverage, the AC-C6T
reduces the number of loudspeakers
required for even coverage in low ceiling
applications.
The easy-to-install blind mount assembly
features a ported baffle which optimally
tunes the galvanized steel backcan for
added musicality, creating low frequency
extension down to 65 Hz. To maintain this
frequency response, the AC-C6T utilizes a
30-watt low-saturation and low-loss 70/100V
transformer with varying selectable taps,
including an 8 Ω bypass. The rotary tap
selector switch is accessible under the
painted steel grille.
To further enhance performance and speed
of install with optimum result, advanced
voicing via QSC Intrinsic Correction ™
techniques are obtainable using Q-Sys ™
networked audio processing platforms,
including CXD amplifiers for a complete QSC
systems solution.
Installers will appreciate the 4-pole
Euroblock connector for loop-thru wiring,
located under a quick access swivel plate.
Eliminating the termination hassles of star
topology wiring designs, the generous
Euroblock of the AC-C6T can accept four
18AWG pairs.
A safety tether tab is affixed to the
adjustable conduit clasp plate for seismic-
sensitive installations. C-ring and tile rails
are included with each pair packed
assembly, complete with joining screws and
cut-out template.
The AC-C6T baffle and grille are QSC
standard white (RAL 9010) to match
complimenting QSC product families and
includes UV inhibitors to prevent
discoloration over time. The AC-C6T may
also be painted to match any décor.
For your system integration needs, complete
EASE, CF2, CAD, and BIM files are available
for download at QSC.com.
Two-way, ceiling mount
loudspeaker
AcousticCoverage™ Series
AC-C6T
