Decide Where to Install the Motherboard
決定主板安裝位/ Décidez où installer la carte mère / Entscheiden Sie, wo das Motherboard installiert werden soll
/Decide dónde instalar la placa base / マザーボードの設置場所を決める
A. Water cooling mode (standard mode)
A. ⽔冷模式(標配模式)
銅 柱 位 置 皆 朝 下 。
The stand-off bolts mount at
the downward arrow position.
Fan Supports for Water Cooling Mode
⽔ 冷 模 式 的 ⾵ 扇 安 裝 限 制
120 mm FAN x 3
140 mm FAN x 2
360 mm RADIATOR (overall thickness < 7 7 mm)
280 mm RADIATOR (overall thickness < 60 mm)
Please refer to page 12 for installation
120 mm FAN x 3
140 mm FAN x 2
160 mm FAN x 2
(500~1680 RPM / 118.85CFM/
3.10 mm H2O)
360 mm RADIATOR
280 mm RADIATOR
Please refer to page 13
for installation
120 mm FAN x 1
140 mm FAN x 1
(200~1800 RPM/
81.30 FM / 2.40 mm H2O)
120 mm FAN x 2
Please refer to page 14
for installation
