UPGRADING YOUR COMPUTER - 15
Installing the Graphics board
1.
Remove the new graphics board from its
packaging.
2.
Insert the graphics boards into the PCIE x16
slot and press it down until it latches into place.
3.
Press the metal clip to secure the graphics
board bracket.
Note
To replace/upgrade graphic board, please check the specification of graphic
board & power supply first in order to make sure the graphic board and power
supply could work.
