100 SERIES
9
U s e r m a n u a l
100 ICW 5
100 ICW 6
100 IC 6ST
Type
In-wall/In-celling
2-way coaxial
In-wall/In-celling
2-way coaxial
In-celling stereo
2-way coaxial
Drivers
5"
(13cm)
Polyglass
Midbass.
1"
(25mm)
AI inverted
dome Tweeter
6
1/2
"
(16,5cm)
Polyglass
Midbass.
1"
(25mm)
AI inverted
dome Tweeter
6
1/2
"
(16,5cm)
Dual voice
coil Polyglass
Midbass.
1"
(25mm)
AI inverted
dome Tweeter
Sensitivity (2.83V/1m)
88dB
89dB
89dB
Frequency response (+/-3dB)
65Hz-23kHz
62Hz-23kHz
60Hz-23kHz
Low frequency point (-6dB)
56Hz
50Hz
48Hz
Nominal impedance
8Ώ
8Ώ
2x8Ώ
Minimal impedance
7.3Ώ
7.3Ώ
2x6.7Ώ
Recommended amplifier power
15-100W
25-100W
25-100W
External dimensions (Ø/Depth)
7
1/4
"x3
27/64
"
(184x87mm)
8
3/16
"x3
47/64
"
(208x95mm)
8
3/16
"x3
47/64
"
(208x95mm)
Cut-Out diameter
6
19/64
"
(160mm)
7
1/4
"
(184mm)
7
1/4
"
(184mm)
Depth from wall
3
15/64
"
(82mm)
3
37/64
"
(91mm)
3
37/64
"
(91mm)
Net weight (with front grille)
3.19lbs
(1.45kg)
3.3lbs
(1.50kg)
3.86lbs
(1.75kg)
Packing dimensions (WxDxH)
9
5/8
"x9
5/8
"x6
5/16
"
(245x245x161mm)
10
5/8
"x10
5/8
"x6
11/16
"
(270x270x170mm)
10
5/8
"x10
5/8
"x6
11/16
"
(270x270x170mm)
Total weight (with packaging)
4.52lbs
(2.05kg)
4.96lbs
(2.25kg)
5.29lbs
(2.40kg)
100 ICW 8
100 ICLCR 5
Type
In-wall/In-celling
2-way coaxial
In-ceiling
2-way
Drivers
8"
(21cm)
Polyglass
Midbass.
1"
(25mm)
AI inverted
dome Tweeter
2 x 5"
(13cm)
Polyglass woofers
1"
(25mm)
AI inverted dome tweeter
8"
(21cm)
Polyglass passive radiator
Sensitivity (2.83V/1m)
90dB
92dB
Frequency response (+/-3dB)
53Hz-23kHz
65Hz - 23kHz
Low frequency point (-6dB)
40Hz
55Hz
Nominal impedance
8Ώ
8Ώ
Minimal impedance
6.9Ώ
4.6Ώ
Recommended amplifier power
25-150W
25-120W
External dimensions
(Ø/Depth)/(HxWxD)
9
49/64
"x4
3/8
"
(248x111mm)
13
15/16
"x13
15/16
"x5
5/16
"
(354x354x150mm)
Cut-Out diameter
8
13/16
"
(224mm)
12
15/16
"x12
15/16
"
(328x328mm)
Depth from wall
4
7/32
"
(107mm)
6"
(152mm)
Net weight (with front grille)
3.86lbs
(1.75kg)
5.3kg
Packing dimensions (WxDxH)
12
3/16
"x12
3/16
"x7
1/4
"
(310x310x185mm)
16
1/16
"x16
1/16
"x7
1/2
"
(408x408x190mm)
Total weight (with packaging)
5.73lbs
(2.60kg)
15.8lbs
(7.20kg)
