3. Setup
AC Power
This product requires an external power supply, which is included. The included
power supply is rated for 100–240 VAC, 50/60 Hz, 500 mA max. Before powering on
the unit, make sure the line voltage to which you are connecting it is within the range
of accepted voltages listed on the label affixed to the product or refer to the
Technical Specifications. The listed current rating indicates average current draw
under normal conditions.
•
Always connect the fixture to a grounded circuit. Never connect the fixture
to a rheostat (variable resistor) or dimmer circuit, even if the rheostat or
dimmer channel is used only as a 0 to 100% switch.
•
To eliminate wear and improve its lifespan, during periods of non-use
completely disconnect from power via breaker or by unplugging it.
Mounting
Before mounting the product, read and follow the safety recommendations indicated
in the Safety Notes.
Orientation
The Obey 70 may be mounted in any position; make sure adequate ventilation is
provided around the product.
Rigging
•
Choose a location for the product that gives easy access for maintenance and
programming.
•
Make sure that the structure or surface onto which you are mounting the product
can support the product’s weight (see Technical Information).
•
When rigging the product onto a truss, you should use a mounting clamp of
appropriate weight capacity and a safety cable.
Product
Addressing
The Obey 70 can control up to 12 separate fixtures. Each fixture must be set to
predetermined DMX addresses. Please see the chart below for the DMX starting
addresses of each of the 12 fixtures.
Product Address DIP
switch Product Address
DIP
switch Product Address
DIP
switch
1
1
1
5
129
1,8
9
257
1,9
2
33
1,6
6
161
1,6,8
10
289
1,6,9
3
65
1,7
7
193
1,7,8
11
321
1,7,9
4
97
1,6,7
8
225
1,6,7,8
12
353
1,6,7,9
