ADX40
OVERVIEW
The ADX40 is a miniaturized condenser microphone designed to hang from an
overhead position for applications such as group vocals, choir, theatrical production
and room ambience. Known for its clarity, resistance to feedback, and ease of
operation, the ADX40 has the ability to accurately capture and reproduce sound from
a distance.
The ADX40 is characterized with a uniformly controlled cardioid polar pattern, helping
to isolate the area or section being miked from other vocals or instruments on stage.
The ADX40 is also available in a hypercardioid polar pattern (model ADX40HC) for
tighter pick-up control. With a wide frequency range of 40 Hz - 20 kHz, the ADX40
provides natural sound with exceptional transient response.
The ADX40 is supplied with an attached 30’ cable, external windscreen, wire hanger
for positioning and phantom power adapter. Manufactured with very high standards
and tight tolerances, the ADX40 features a machined brass body, field replaceable
capsule and a variety of optional accessories. The ADX40 is available in non-reflective
black or white finish (ADX40W).
MODEL VARIATIONS
ADX40W - Same as above in white
ADX40HC - Hypercardioid capsule in black
ADX40WHC - Hypercardioid capsule in white
SUPPLIED ACCESSORIES
APS910 - Cylindrical preamplifier for use with phantom power
HANGER40 - Wire hanger
P1 - Carrying pouch
- 30’ attached shielded cable with mini XLR-f connector
WS20 - External foam windscreen (black) or WS20W (white)
OPTIONAL ACCESSORIES
APS911 - Battery/phantom preamplifier with on/off switch and roll-off
MCHANGER - Clear plastic clip
MCMICRO - Microphone stand adapter
MCSWIVEL - Shockmount adapter with ball and socket pivot
SMTMICRO - Microphone stand adapter with shockmount ring
OVERHEAD CONDENSER
MICROPHONE
ADX40
FEATURES
· Small, lightweight, low profile
· Excellent for distance miking
· Available in 2 polar patterns
· Available in black or white
APPLICATIONS
· Overhead mic for choir, group vocal
· Orchestra miking
· Ambient room miking
· Symphonic area miking
· School plays, theatrical productions
REPLACEMENT CAPSULES
CPSADXC - Cardioid in black
CPSADXCW - Cardioid in white
CPSADXHC - Hypercardioid in black
CPSADXHCW - Hypercardioid in white
APS910 ADX40 P1 WS20 APS911 MCHANGER MCMICRO MCSWIVEL SMTMICRO
on HANGER40
