Xvive Audio P3 Mono Bluetooth Audio Receiver - Manual

SHENZHEN FZONE TECHNOLOGY CO., LTD.
2nd floor, Building 12, Xicheng Industrial Area, Xixiang Town,
Baoan District, Shenzhen Guangdong China. 518101
www.xvive.com
Made In China
SAFETY INSTRUCTIONS FOR LITHIUM-ION
RECHARGEABLE BATTERIES
FCC CERTIFICATION
CAUTION:
RISK OF ELECTRIC SHOCK—DO NOT OPEN
If abused or misused, the rechargeable batteries may leak. In
extreme cases, they may even present a risk of explosion, fire,
heat, smoke or gas. Xvive does not accept any liability for damage
arising from abuse or misuse.
• Keep away from children.
• Only charge rechargeable batteries with chargers
recommended by Xvive.
• Observe correct polarity.
• Pack/store charged rechargeable batteries so that the terminals
cannot contact each other (danger of shorting out/fire hazard).
• Do not expose to moisture.
• Switch rechargeable battery-powered products off after use.
• Only charge rechargeable batteries at ambient temperatures
between 10°C/50°F and 40°C/104°F.
• When not using rechargeable batteries for extended periods
of time, charge them regularly (about every three months).
• Do not mutilate or dismantle.
• Do not heat above 60°C/140°F, e.g. do not expose to sunlight
or throw into a fire.
• Immediately remove rechargeable batteries from obviously
defective products.
• Do not continue to use defective rechargeable batteries.
• Only use rechargeable batteries specified by Xvive.
• Dispose of rechargeable batteries at special collection points
or return them to your specialist dealer.
• Store the products in a cool and dry place at room
temperature (approx. 20°C/68°F).
• Remove the rechargeable batteries if the products will not
be used for extended periods of time.
1. Observe all instructions in the manual carefully.
2. Do not to perform service operations beyond those
described in the manual. Service is required when
the apparatus has been damaged in any way, such as:
• Liquid has been spilled or objects have fallen into the
apparatus
• The unit has been exposed to rain or moisture
• The unit does not operate normally or changes in
performance in a significant way
• The unit is dropped or the enclosure is damaged
3. Do not place near heat sources, such as radiators, heat
registers, or appliances which produce heat.
4. Guard against objects or liquids entering the device.
Do not use or place unit near water.
5. Clean only with a dry cloth.
6. Only use attachments/accessories specified by the
manufacturer.
WARNING:
BEFORE USING YOUR PRODUCT,
CAREFULLY READ THE OPERATING INSTRUCTIONS:
IMPORTANT SAFETY INSTRUCTIONS:
PLEASE READ THESE INSTRUCTIONS
AND KEEP IN A SAFE PLACE
INFORMATION ABOUT COLLECTION
AND DISPOSAL OF OLD ITEMS
AND USED BATTERIES
PAIRING WITH P3
LED ACTIVITY
STEREO-LINKING TWO P3 UNITS
OVERVIEW
SPECIFICATIONS
LEGAL DISCLAIMER
P3 TROUBLESHOOTING
LIMITED WARRANTY
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
WARNING:
Changes or modifications not expressly approved in writing
by XVIVE may void the user’s authority to operate this equipment.
RF EXPOSURE STATEMENT:
This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. There
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Hereby, SHENZHEN FZONE TECHNOLOGY CO., LTD,
declares that this type of equipment is in compliance with
the essential requirements and other relevant provisions of
Directive 2014/53/EU
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THE APPLIANCE TO RAIN OR MOISTURE.
This Class B digital apparatus complies with Canadian ICES-003.
IC Caution: RSS-Gen Issue 4 December 2014"&"CNR-Gen 4e
Décembre 2014:
This device complies with Industry Canada licence-exempt
RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le present appareil est conformé aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
Cd
To protect our environment, please take old products and
used batteries to proper collection places; and, in the EU,
follow your national legislation and the Directives 2012/19/EU
and 2006/66/EC.
When disposing of old products and batteries, please help to
save valuable resources and prevent any possibilities of side
effects on human health and the environment.
You can contact your local authority to find out how to
dispose of old products and used batteries responsibly.
For product owners in the European Union:
If you want to discard electrical and electronic items, please
contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the
European Union:
Please contact your local authorities or dealer for more
information regarding the disposal of old items and used
batteries.
The symbols shown below are valid only in the European
Union. They indicate that you must not mix used electronic
products and batteries with general household garbage.
• XLR-output Bluetooth audio receiver for mixers and active
PA speakers
• Connects smartphones & laptop to audio broadcast systems
via Bluetooth to amplify music or other audio
• The P3 set includes one P3 Bluetooth audio receiver for
mono audio
• The P3D set includes two P3 Bluetooth audio receivers for
dual mono or stereo audio. Two P3 units can be linked in
order to receive a stereo signal
• Internal rechargeable battery provides 6 hours of operation
• USB Type-C port for charging via any 5V USB power source
• Stable connectivity over a 100 ft range (line-of-sight without
obstacles). Gives you ample coverage for parties, events and
weddings
The Charging LED illuminates whenever P3 is connected to
USB power. It’s solid red when the unit is charging, and turns
to solid green when the unit is fully charged.
The Power and Battery Status LED illuminates whenever P3 is
powered on. When battery strength is above 31%, the LED will
be solid red. When battery strength is less than 30%, it will
flash every three seconds. When the battery strength is less
than 5%, it will flash every 0.5 seconds, indicating that the unit
needs to be recharged.
1. Follow steps 1-5 in “PAIRING WITH P3”.
2. Press and hold the Stereo-Link button for 3 seconds on the
primary (left channel) P3. Press and hold the Stereo-Link
button for 3 seconds on the secondary (right channel) P3.
3. Both Stereo-Link LEDs will flash while the P3 units search for
each other.
4. When they are successfully linked, each P3 will produce a
confirmation tone and the Stereo-Link LEDs on both units
will be on.
NOTE: Before pairing, ensure that there are no wifi devices
(such as wireless routers) in the area.
NOTE: If the connection is not successful, please wait for the
connection, or reset the P3 power and smartphone Bluetooth
function before trying to connect again.
NOTE: When wirelessly connected to a single loudspeaker,
the left and right audio signals will be summed to mono.
NOTE: When a battery is not available, the P3 can be powered
by a regular 5V USB adapter.
XVIVE accepts no liability for any loss which may be suffered
by any person who relies either wholly or in part upon any
description, photograph, or statement contained herein.
Technical specifications, appearances and other information
are subject to change without notice.
For the applicable warranty terms and conditions and additional
information regarding the XVIVE Limited Warranty, please
email [email protected]
1. Power on your P3 device.
2. The system will automatically search for Bluetooth sources
when powered on; but you can press and hold the Pair
button for 3 seconds to activate—the Bluetooth LED will
flash when P3 is in pairing mode.
3. On your smartphone or tablet, turn on Bluetooth, find "P3"
in the devices list, and connect to it.
4. When paired successfully, a confirmation tone will sound
and the blue Bluetooth LED will illuminate.
5. Adjust the volume as desired on your smartphone/tablet
and mixer.
XLR output
Type-C USB
charging port
Charging LED
Stereo-link LED
Stereo-link
pairing button
STEREO-LINK
PAIR
PAIR
Power on/off
Power and
Battery Status LED
P3
For Mixers and Active PA/DJ Systems
Live sound mixer
Smartphone
Laptop
Portable integrated PA system
Digital audio recorder
Active loudspeaker
STEREO-LINK
P3
Bluetooth LED
Bluetooth
pairing button
STEREO-LINK
PAIR
P3
ST EREO-LINK
PAIR
P3
ST EREO-LINK
PAIR
P3
Dimensions: 24 x 24 x 116.5 mm
Weight: 0.12 lbs / 52g
XLR output: XLR male, balanced
Output level: +4 dBu
Bluetooth profiles: 5.1, A2DP, AVRCP
Supported Bluetooth codecs: SBC, AAC
Bluetooth range: Up to 100 feet (30.5 m)
Frequency band: 2402 to 2480 MHz
Battery life: Up to 6 hours
Recharging time: Up to 2 hours
USB charging: Type-C 5V, 500 mA
A2DP frequency response: 20 Hz - 20 kHz (ref 1 kHz, ± 3 dB)
DAC resolution: 16-bit, 48 kHz
Rechargeable battery: Built-in lithium-ion 300 mAh
BLUETOOTH LED/STEREO LINK LED IS FLASHING
• P3 is searching for a Bluetooth device; pair with a smartphone
or computer following the “PAIRING WITH P3” instructions.
• The device could be outside the working range of the Bluetooth
connection. Bring the P3 and smartphone/laptop closer
together; when within range, connection should happen
automatically.
BLUETOOTH LED/STEREO LINK LED IS OFF
• Pairing is unsuccessful. Check the directions in “PAIRING WITH
P3” and make sure the devices are not too far apart.
The connected devices must remain within working range
during use in order for the connection to remain stable.
SMARTPHONE/COMPUTER ALWAYS SEARCHING,
CANNOT PAIR
• Wait for the Bluetooth connection to be made
• Turn off the power and turn it on again
VOLUME TOO LOW / NO SOUND
• Turn up the volume on your smartphone/pad/computer
• Turn up the volume on the mixer or connected device
WARNING TONE
• A tone will sound when Bluetooth is successfully connected
or disconnected
• When Bluetooth is searching there is no warning tone
CANNOT CHARGE / NOT WORKING
• Check charger connections to the P3 and power source
• Contact Xvive for warranty support
L
R
L+R
Stereo-Link Two P3s
One P3 for Mono audio
P3 P3D
