Designed to eliminate the extra step of finishing the screen with trim,
the Advantage line of projection screens is designed with ceiling trim
already in place. Once the screen is installed, the screen’s trim con-
ceals the rough opening eliminating the need to complete additional
trim work.
Sliding installation brackets make it easy to attach the screen hous-
ing to the structure above the drop ceiling.
The Advantage® Electrol® screen features simple in ceiling installa-
tion that can be done in two stages. The screen case can be installed
during the rough-in construction stage and the fabric assembly can
be completed during the finishing stage.
The Advantage Electrol does not include the automatic closure door
or the Tensioning Cable System. See Tensioned Advantage Electrol
for Tensioning Cable System or Tensioned Advantage Deluxe
Electrol for both the Tensioning Cable System and the additional aes-
thetic of the automatic closure door.
Features
• Standard Silent Drive System to keep your screen whisper quiet (sizes up
to 10’x10’)
• Standard Low Voltage Control (LVC) to keep your screen operation flexible
• Simple Installation with a new installation kit and user-friendly packaging to
keep you on schedule
• Support includes a comprehensive five-year warranty to keep you
confident in your purchase
• UL Plenum rated case
• White powder-coated case for a clean aesthetic
• Available with SCB-100 or SCB-200 (RS-232 serial control board) built into
the case (adds 10" to overall length of case)
• Available with Video Projector Interface (screen trigger) built into the case
(adds 10" to overall length of case of 220V motor version)
• Decora-style, three-button wall switch
• Standard black backing retains projected brightness
• Seamless surfaces in all models
Optional Accessories:
• Radio Frequency Wireless Remote
• Infrared Wireless Remote
• Locking Switch Cover Plate
• Red Laser Pointers
• Green Laser Pointers
• RF PowerPoint Remote with
Green Laser Pointer
4:3 Video Format
Viewing Area (H x W) Nominal Diagonal Overall Case Length*
in. cm in. cm in. cm
43" x 57" 109 x 145 72" 183 65½" 166
50" x 67" 127 x 170 84" 213 75½" 192
57" x 77" 145 x 196 96" 244 89½" 227
60" x 80" 152 x 203 100" 254 89½" 227
69" x 92" 175 x 234 120" 305 101½" 258
87" x 116" 221 x 295 150" 381 125½" 319
105" x 140" 267 x 356 180" 457 149½" 380
120" x 160" 305 x 406 200" 508 169½" 431
16:9 HDTV Format
Viewing Area (H x W) Nominal Diagonal Overall Case Length*
in. cm in. cm in. cm
45" x 80" 114 x 203 92" 234 89½" 227
52" x 92" 132 x 234 106" 269 101½" 258
54" x 96" 137 x 244 110" 279 105½" 268
58" x 104" 147 x 264 119" 302 113½" 288
65" x 116" 165 x 295 133" 338 125½" 319
78" x 139" 198 x 353 159" 404 149½" 380
90" x 160" 229 x 406 184" 467 169½" 431
16:10 Wide Format
Viewing Area (H x W) Nominal Diagonal Overall Case Length*
in. cm in. cm in. cm
50" x 80" 127 x 203 94" 239 89½" 227
57½" x 92" 146 x 234 109" 277 101½" 258
60" x 96" 152 x 244 113" 287 105½" 268
65" x 104" 165 x 204 123" 312 113½" 288
69" x 110" 175 x 279 130" 330 119½" 304
72½" x 116" 184 x 295 137" 348 125½" 319
87" x 139" 221 x 353 164" 417 149½" 380
100" x 160" 254 x 406 189" 480 169½" 431
Advantage Electrol
*Case length does not include trim flange
