Peak SPL is measured on-axis at 1 m, with dynamic pink noise

Specifications subject to change without notice.

Compact Powered Loudspeakers

CP8

CP12

Configuration:

Two-way active loudspeaker

LF Transducer:

8 in (203 mm), cone

12 in (305 mm), cone

HF Transducer:

1.4 in (35.6 mm) compression driver

Frequency Response (-6 dB):

56 - 20 kHz

49 - 20 kHz

Frequency Range (-10 dB):

53 - 20 kHz

47 - 20 kHz

Nominal Coverage Angle:

90° Axisymetric

75° Axisymetric

Maximum Rated SPL

124 dB

126 dB

Amplifier:

Class D

Peak: 800 W (LF), 200 W (HF)

Controls:

Power

2 x Gain

Mic Boost Push Switch

6-way Contour Selection Switch

Indicators:

Power LED

2 x Input Signal LED

Input B MIC selected LED

Limiter active LED

Connectors:

2 x locking XLR/F ¼” combo (Line Input and Mic/Line input)

1 x 3.5 mm TRS (Stereo Input)

1 x XLR/M (Mix Output)

1 x IEC power connector

AC Power Input:

Universal power supply 100 – 240 VAC, 50 – 60 Hz

AC Power Consumption 1/8th Power:

100 VAC, 0.75A / 120VAC, 1.0A / 240VAC 0.31A

Enclosure Material:

Polypropylene

Attachment Points:

M10 threaded insert

Color:

Black (RAL 9011)

Grille:

18 Gauge powered coated steel

Dimensions (HxWxD):

16.2 x 10.7 x 10.1 in

20.3 x 13.8 x 12.7 in

411 x 273 x 256 mm

516 x 350 x 323 mm

Net Weight:

21.0 lbs (9.5 kg)

30.3 lbs (13.7 kg)

Shipping Weight:

25.5 lbs (11.4 kg)

36.3 (16.5 kg)

Regulatory:

EMC, UL, CB

Optional Accessories:

CP8 Tote, CP8 Outdoor Cover

CP12 Tote, CP12 Outdoor Cover

CP8 Yoke

CP12 Yoke

P R E L I M I N A RY
