AudioEngine S8 8" 250W Subwoofer (Black) - Manual

A5 A2 AS8 AW1 AW2
Audioengine S8 Upgrade your audio Premium Powered Subwoofer
Features:
• Super-compact size
• 8" custom downfiring woofer
• Wireless-ready!
• Solid hand-finished, front-ported cabinet
• Auto-sleep power saving mode
• Dual line-level inputs (RCA and mini-jack)
• All cables included
• Excellent performance for music, movies,
and videogames
• A perfect bass extension for Audioengine
powered speakers or any audio system!
Audioengine S8 with A5 and A2
Back
11¼”
Output
(Line-level)
Mini-Jack Input
11 ¼”
LFE IN
FOR 110–120V: T3.15AL FOR 220–240V: T2AL
110–120V 2.5A ~AC 220–240V 1.6A 60Hz/50Hz Replace with same rating and type
AS8
120W MAX
AUX OUTLET Unswitched
110–120VAC 60Hz 1A 220–240VAC 50Hz 0.5A
INPUTS A
L
R
B OUTPUT
AC SELECT
11 5
RCA Input
Phase
Crossover
Volume
AC Select
Power Switch
Power Inlet
Fuse
Aux AC
Outlet
LFE In
• AC power cable
• 1/8” mini-jack audio cable,
2 meters (~6.5 feet)
• RCA audio cable, 2 meters (~6.5 feet)
• Drawstring cable bag
• Drawstring subwoofer bag
• Setup guide
Included Accessories:
This is a well-made, solid
sounding subwoofer, with the
potential for a wireless twist.
-What Hifi?
Type:
Power output:
Amplifier Type:
Inputs:
Output:
Voltages:
Driver:
Ports:
Signal-to-noise:
THD:
Freq. Response:
Sensitivity:
Input impedence:
Crossover Frequency:
Phase:
Standy power Consumption:
Protection:
Dimensions (HxWxD):
Shipping weight:
Powered Subwoofer
250W peak power total (125W RMS), AES
Dual Class AB monolithic
1⁄8” (3.5mm) Stereo mini-jack and RCA L/R
RCA L/R, full-range
115/230V, 50/60Hz manually switchable
8” long-throw woofer, downfiring design
Single, front
>95db (typical A-weighted)
<0.05% at all power settings
27Hz-180Hz (±1.5db)
88db SPL (1w@1m)
10K ohms unbalanced
50Hz - 130Hz
0 - 180°
8W
Output current limiting, thermal over-temperature,
power on/off transient protection
11.25” x 11.25” x 11.25”
13.6kg (30 lbs)
General Specifications
