Data sheet | HP ZBook Studio 16 inch G9 Mobile Workstation PC
HP recommends Windows 11 Pro for business
HP ZBook Studio 16 inch G9 Mobile Workstation PC Specications Table
*Product image may differ from actual product
Available Operating Systems
Windows 11 Pro – HP recommends Windows 11 Pro
Windows 11 Home – HP recommends Windows 11 Pro for Business
Windows 10 Pro (available through downgrade rights from Windows 11 Pro)
Ubuntu 20.04
FreeDOS 3.0
Processor family 12th Generation Intel® Core™ i7 processor; 12th Generation Intel® Core™ i9 processor
Available Processors
Intel® Core™ i7-12700H with Intel® UHD Graphics (2.3 GHz base frequency, up to 4.7 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 14
cores, 20 threads); Intel® Core™ i7-12800H with Intel® UHD Graphics (2.4 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology,
24 MB L3 cache, 14 cores, 20 threads), supports Intel® vPro® Technology; Intel® Core™ i9-12900H with Intel® UHD Graphics (2.5 GHz base
frequency, up to 5.0 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 14 cores, 20 threads), supports Intel® vPro® Technology; Intel®
Core™ i9-12900HK with Intel® UHD Graphics (2.5 GHz base frequency, up to 5.0 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 14 cores,
20 threads)
Maximum memory
64 GB DDR5-4800 non-ECC SODIMM
Memory is SODIMM. Supports dual channel memory.
Memory slots 2 SODIMM; supports dual channel
Internal storage 256 GB up to 4 TB PCIe® Gen4 x4 NVMe™ M.2 SSD
Display size (diagonal, metric) 40.6 cm (16")
Display
40.6 cm (16") diagonal, 4K WQUXGA (3840 x 2400), 120 Hz, IPS, anti-glare, 500 nits, 100% DCI-P3, HP DreamColor; 40.6 cm (16") diagonal, 4K
WQUXGA (3840 x 2400), OLED, multitouch-enabled, UWVA, BrightView, Corning® Gorilla® Glass 5, Low Blue Light, 400 nits, 100% DCI-P3; 40.6 cm
(16") diagonal, WUXGA (1920 x 1200), IPS, anti-glare, 1000 nits, 72% NTSC, HP Sure View Reect integrated privacy screen; 40.6 cm (16") diagonal,
WUXGA (1920 x 1200), IPS, narrow bezel, anti-glare, Low Blue Light, 400 nits, low power, 100% sRGB
Available Graphics Integrated: Intel® Iris® X ᵉ Graphics
Audio
Audio by Bang & Olufsen, Quad-speaker audio (2 tweeters & 2 Quad woofers), 2 Top Facing Microphone dual array digital microphones, functions
keys for volume up and down, combo microphone/headphone jack, HD audio with 200Hz Bass Roll off
Ports and Connectors
Left side: 1 power connector; 1 headphone/microphone combo; 2 Thunderbolt™ 4 with USB4™ Type-C® 40Gbps signaling rate (USB Power
Delivery, DisplayPort™ 1.4, HP Sleep and Charge) ;
Right side: 1 Super Speed USB Type-A 5Gbps signaling rate (charging); 1 SuperSpeed USB Type-C® 10Gbps signaling rate (USB Power Delivery,
DisplayPort™ 1.4)
Input devices
HP Premium Quiet Keyboard – spill-resistant, full-size, backlit keyboard with drain and DuraKeys; HP RGB Keyboard - Full-size, per-key RGB backlit
keyboard; HP RGB Z Command Keyboard – spill-resistant, full-size, backlit keyboard with drain and DuraKeys; Clickpad with image sensor,
supporting multi-touch gestures and taps;
Communications
WLAN: Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.2 M.2 combo, vPro®; Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.2 M.2 combo, non-vPro®
;
Camera 720p HD IR camera
Software
Bing search for IE11; Buy Office; HP Hotkey Support; HP Noise Cancellation Software; HP Performance Advisor; HP Support Assistant; Native
Miracast support; HP Connection Optimizer; HP Privacy Settings; HP QuickDrop; Data Science Stack; HP Easy Clean; HP PC Hardware Diagnostics; HP
ZCentral Remote Boost 2020 Software for Z workstation; Tile™ Application; Windows 10 Cloud Recovery Client; 1-month Adobe® free trial offer; HP
Z Light Space; HP Camera & Super Resolution Software;
Available software HP Smart Support
Security management
Absolute persistence module; HP Device Access Manager; HP Power On Authentication; Trusted Platform Module TPM 2.0 Embedded Security Chip;
Master Boot Record security; Pre-boot authentication; Windows Defender; HP Manageability Integration Kit; HP BIOSphere Gen6; HP Sure Start
Gen6; HP Sure Admin; HP Image Assistant; HP Tamper Lock; MS Bitlocker Encryption; Nano Security Lock Slot; HP Client Security Manager Gen7; HP
Privacy Key;
Security Software Licenses HP Wolf Pro Security Edition
Fingerprint reader Fingerprint sensor (select models)
Management features HP Power Manager
Power HP Slim Smart 150 W External AC power adapter; HP Slim Smart 200 W External AC power adapter
Battery type HP Long Life 6-cell, 86 Wh polymer
Dimensions 35.6 x 24.2 x 1.9 cm (non-touch); 35.6 x 24.2 x 1.8 cm (touch)
Weight Starting at 1.73 kg (Weight varies by conguration and components.)
Ecolabels EPEAT® Gold registered in the U.S.
Sustainable impact specications Low Halogen
