TP-Link Deco XE75 AXE5400 Wireless Tri-Band Gigabit Mesh Wi-Fi System (2-Pack) - Manual (Page 4)

· Certification: CE, FCC, RoHS
· Environment:
Operating Temperature: 0°C~40°C (32 °F~104 °F)
Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH
· Package Contents for Deco XE75(1-pack):
1 Deco XE75 unit
1 RJ45 Ethernet cable
1 Power adapter
1 Quick Installation Guide
· Package Contents for Deco XE75(2-pack):
2 Deco XE75 units
1 RJ45 Ethernet cable
2 Power adapters
1 Quick Installation Guide
· Package Contents for Deco XE75(3-pack):
3 Deco XE75 units
1 RJ45 Ethernet cable
3 Power adapters
1 Quick Installation Guide
Others Hardware
Wireless
Software
· Working Mode: Router, Access Point
· WAN Type: Dynamic IP/Static IP/PPPoE/L2TP/PPTP
· DHCP: Server
· Protocols: Supports IPv4 and IPv6
· Guest Network: 2.4 GHz Guest Network×1, 5 GHz Guest Network×1, 6 GHz
Guest Network×1
· Features: TP-Link HomeShield, BSS Color △ , OFDMA △ , 1024-QAM △ ,
MU-MIMO △ , Optional Ethernet Backhaul, Assisted Setup, Address
Reservation, Port Forwarding, TP-Link DDNS, IPTV, IPv6, Firewall Rules,
LED Control
· Management: Local Management; Remote Management; Multi-Managers
· Wireless Standards: IEEE 802.11a/n/ac/ax 5 GHz,
IEEE 802.11b/g/n/ax 2.4 GHz, Wi-Fi 6E Mesh
· Mesh protocol: 802.11k/v/r
· Frequency: 2.4 GHz, 5 GHz and 6 GHz
· Signal Rate: 2402 Mbps on 6 GHz + 2402 Mbps on 5 GHz+ 574 Mbps on
2.4 GHz †
· Transmit Power: FCC: <30 dBm(2.4 GHz), <30 dBm(5 GHz), <30 dBm(6
GHz)
CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz), <23 dBm (6 GHz)
· Wireless Security: WPA/WPA2-PSK/WPA3 encryptions
Specifications
· Ether net Port: 3 Gigabit ports per Deco unit (WAN/LAN auto-sensing)
· Button: 1 RESET button on the back
· Antenna: 4 high-gain antennas
· Power Consumption (with power adapter): 23 W max
· Dimensions (W × D × H): 4.1 Ч 4.1 Ч 6.7 in (105 Ч 105 Ч 169 mm)
· Power Adapter Input: 100-240 V ~ 50/60 Hz 0.8 A
· Power Adapter Output: 12 V 2 A
TP-Link AXE5400 Tri-Band Mesh Wi-Fi 6E System Deco XE75
Attention: This device may only be used indoors in all EU member states, EFTA countries and Northern Ireland.
Attention: This device may only be used indoors in Great Britain.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Specifications are subject to change without notice. All the brands and product names are trademarks or registered trademarks of their respective holders.
† Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput, wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including
building materials, obstacles, volume and density of traffic, and client location.
‡ Clients need to support 802.11k/v/r and may require additional setup. Performance may vary depending on the client device.
△ Use of Wi-Fi 6, Wi-Fi 6E, and other features including OFDMA, MU-MIMO, 1024-QAM, and BSS Color require clients to also support the corresponding features. The 160 MHz bandwidth may be unavailable in the 5 GHz band in some regions/countries due to regulatory restrictions.
* HomeShield includes the Free Basic Plan. Fees apply for the Pro Plan. Visit tp-link.com/homeshield for more information.
©2021 TP-Link
