IOGear Ethernet-2-WiFi Universal Wireless Adapter - Manual (Page 3)

Specifications
Function GWU637
Operating Temperature 0 ~ 50ºC
Storage Temperature -10 ~ 70ºC
Humidity 5 ~ 90% (Non Condensing)
Transmission Power
IEEE 802.11n: <13dBm, IEEE 802.11b:
<17dBm, IEEE 802.11g: <15dBm
Frequency Band 2.4GHz ISM Band
Modulation BPSK / QPSK / 16-QAM / 64-QAM
Data Rate
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 60,
90, 120 and up to 300Mbps
Security
64-bit or 128-bit WEP / TKIP / AES / WPA /
WPA2
Operating Range Indoor: up to 100m, Outdoor: up to 180m
Encryption
64-bit or 128-bit WEP / TKIP / AES / WPA /
WPA2
Antenna Type 2T2R
Standards IEEE 802.11b/g/n, 802.3, 802.3u
Network Interface
One 10/100 BaseT with RJ45 port
(WAN/LAN)
Power
Amps 5V
Voltage 500mA
Power Connections Micro USB
Dimensions GWU637
Unit Dimensions
Height 1" (2.5cm)
Depth 0.75" (1.9cm)
Length 2.56" (6.5cm)
Inner Pack
Width 9.5" (24.1cm)
Height 7.5" (19.05cm)
Depth 14.25" (36.2cm)
Inner Pack Qty. 6
Unit Package Dimensions
Width 6.37" (16.2cm)
Height 9.06" (23.01cm)
Depth 2.25" (5.7cm)
Master Carton
Width 10.5" (26.7cm)
Height 17.25" (43.8cm)
Depth 15.75" (40cm)
Master Carton Qty. 12
Weight
Master Carton Wt. 9.8lb (4.4kg)
Inner Pack Wt. 4.2lb (1.9kg)
Unit Pack Wt. 0.55lb (0.26kg)
Unit Wt. 0.05lb (0.02kg)
GWU637
© 2015 IOGEAR®
IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of their respective holders.
IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR assumes no responsibility for any inaccuracies or
errors that may appear in this document.
Ethernet-2-WiFi Universal Wireless Adapter
