ARRI SkyPanel S360-C LED Softlight (Blue/Silver, Manual, Standard Diffusion, Edison) - Manual

SkyPanel is a compact, ultra-bright and high-quality LED soft light that sets a new standard for
the industry. With a design focused on form, color, beam field and output, SkyPanel represents
the culmination of more than a decade of research and development of LED technology at ARRI.
SkyPanel is available in several sizes: the S30, S60, S120, and S360. The S60 is a mid-range
model, featuring a light aperture of 645 x 300 mm and accommodating the vast majority of
applications. The S120 is twice as long as the S60, but weighs nearly the same. Its larger light
aperture makes a great soft light even better. The S30 is a smaller, more portable version; half
the length of the S60, it is perfect for on-the-go mobile applications. The S360 is the largest and
brightest SkyPanel with four times the output of the S60 and almost six times the aperture size.
The S360 is perfect for lighting large areas with tuneable, soft light. S30 and S60 models are
available in fully color tuneable and remote phosphor versions.
Incorporating features of ARRI’s successful L-Series LED Fresnels, SkyPanel is one of the most
versatile soft lights on the market, as well as one of the brightest. Like the L-Series, SkyPanel
‘C’ (Color) versions are fully tuneable; correlated color temperature is adjustable between 2,800 K and 10,000 K, with excellent color rendition over the
entire range. Full plus and minus green correction can be achieved with the simple turn of a knob, and in addition to CCT control, vivid color selection and
saturation adjustment is also possible.
Unlike other tuneable fixtures, SkyPanel makes no sacrifice when it comes to light output. SkyPanel puts out a tremendous amount of light, in a soft and
uniform beam field. The S360-C is twice as bright as a 4 kW tungsten soft light or three times as bright as a 12 kW tungsten space light. At the same
time, the lamphead is able to perform beautifully at lower light levels. This range of illumination and color gives users an unprecedented amount of control.
Achieving an energy efficiency of over 80 lumens per watt, the S360-C is also one of the most eco-friendly LED soft lights available while also being one of
the brightest.
Made in Germany to the high standards for which all ARRI products are known, SkyPanel is built to last – constructed from resilient materials and assembled
by hand with great care. Other features include LAN port for network connectivity, USB-A port for firmware updates via thumb drive, and many more.
LIGHTING Product Information | December 2017
This ARRI S360-C Product Information (Ident.-No.: 80.0016300) is published by Arnold & Richter Cine Technik, December 2017 © ARRI/2017
Technical data and offerings are subject to change without notice. All rights reserved. Without any warranty. Not binding 12/2017. ARRI, SkyPanel and L-Series are registered trademarks of Arnold & Richter Cine Technik GmbH & Co.
Betriebs KG. ARNOLD & RICHTER CINE TECHNIK · TÜRKENSTRASSE 89 · D-80799 MUNICH · PHONE +49 (0)89 3809-0 · FAX +49 (0)89 3809-1244 · www.arri.com
Photometric Data
3 m / 9.8 ft 5 m / 16.4 ft 7 m / 23.0 ft 9 m / 29.5 ft 12 m / 39.4 ft
S360-C 3,200 K 5,600 K 3,200 K 5,600 K 3,200 K 5,600 K 3,200 K 5,600 K 3,200 K 5,600 K
S360-C with
Standard Diffusion
5,633 lx 5,133 lx 2,028 lx 1,848 lx 1,035 lx 943 lx 626 lx 570 lx 352 lx 321 lx
523 fc 477 fc 188 fc 172 fc 96 fc 88 fc 58 fc 53 fc 33 fc 30 fc
S360-C with
Lite Diffusion
5,767 lx 5,256 lx 2,076 lx 1,892 lx 1,059 lx 965 lx 641 lx 584 lx 360 lx 328 lx
536 fc 488 fc 193 fc 176 fc 98 fc 90 fc 60 fc 54 fc 33 fc 31 fc
S360-C with
Heavy Diffusion
4,633 lx 4,233 lx 1,668 lx 1,524 lx 851 lx 778 lx 515 lx 470 lx 290 lx 265 lx
430 fc 393 fc 155 fc 142 fc 79 fc 72 fc 48 fc 44 fc 27 fc 25 fc
S360-C with
Intensifier
8,333 lx 7,600 lx 3,000 lx 2,736 lx 1,531 lx 1,396 lx 926 lx 844 lx 521 lx 475 lx
774 fc 706 fc 279 fc 254 fc 142 fc 130 fc 86 fc 78 fc 48 fc 44 fc
Order No. Description
L0.0016325 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Standard Diffusion Panel, powerCON 32A Edison cable
L0.0016326 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Standard Diffusion Panel, powerCON 32A Schuko cable
L0.0016327 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Standard Diffusion Panel, powerCON 32A Chinese cable
L0.0016328 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Standard Diffusion Panel, powerCON 32A Japanese cable
L0.0016329 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Standard Diffusion Panel, powerCON 32A Bare Ends
L0.0016330 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Intensifier, powerCON 32A Edison cable
L0.0016331 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Intensifier, powerCON 32A Schuko cable
L0.0016332 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Intensifier, powerCON 32A Chinese cable
L0.0016333 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Intensifier, powerCON 32A Japanese cable
L0.0016334 S360-C, Manual, Blue/Silver, 5 m DC Cable, S360 PSU with Super Clamp Adapter, Intensifier, powerCON 32A Bare Ends
L0.0016335
S360-C Kit
incl. Lamphead & Case, Manual & Short Yoke, PSU & Cables, Standard, Lite & Heavy Diffusion, Intensifier, 30º & 60º Honeycomb, Super Clamp Adapter, SkyPanel Remote
