English 42
Installation instructions
Installation instructions
Re-installing the Oven Door(s)
WARNING
To avoid personal injury or damage to the door from it falling off its hinges:
• Make sure that the notch on the bottom of each hinge rests on top of the lower lip of
each hinge receptacle before attempting to open the oven door.
• Rotate the hinge locks toward the front of the range immediately after installation of
the door.
1. Grasp the oven door on opposite sides and hold it at a 15° angle from the front of the
oven. Slide the hinges into the hinge openings, resting the bottom of the hinge arms
on the hinge receptacles. Continue to hold the door at a 15° angle with one hand while
pushing in on each of the bottom corners of the door. Push until the notch on the
bottom of each hinge slips over the lower lip of each hinge receptacle.
NOTE
Connect the cables at the bottom-right corner of the door.
2. Lower the door to the fully opened position.
3. Rotate the two hinge locks toward the oven.
4. Slowly and carefully open and close the door completely to ensure that it is properly
installed.
5. Remove any packaging from inside the oven(s).
Lower lip of hinge receptacle
Notch on bottom of hinge
Door Installation
