21 INSTALLATION
EN
G
LI
SH
• Install the anti-tip device to the structure and/or
the range. Verify the anti-tip device has been
properly installed and engaged by following the
guide on the anti-tip bracket template.
• Engage the range to the anti-tip device by
following the guide on the anti-tip bracket
template. Ensure the anti-tip device is re-
engaged when the range is moved by following
the guide on the anti-tip bracket template.
• Re-engage the anti-tip device if the range is
moved. Do not operate the range without the
anti-tip device in place and engaged.
• See installation instructions for details.
• Failure to follow these instructions can result in
death or serious burns to children or adults.
• Range must be secured with an approved anti-
tip device.
• The range could be tipped by standing, sitting or
leaning on an open door if the range or anti-tip
device is not properly installed.
• The use of this device does not preclude tipping
of the range when not properly installed.
• After installing the anti-tip device, verify that it is
in place by carefully attempting to tilt the range
forward.
• This range has been designed to meet all
recognized industry tip standards for all normal
conditions.
• The installation of the anti-tip device must meet
all local codes for securing the appliance.
Using the Anti-Tip Bracket Template
• The anti-tip bracket is packaged with an
installation template. The instructions include
necessary information to complete the
installation. Read and follow the range
installation instruction sheet.
• Screws c must enter wood or concrete.
a Anti-tip bracket
b Wall plate
Engaging the Anti-tip Device
a Anti-tip bracket
b Leveling leg
1
Slide the range against the wall, making sure
the back leg slides into and engages the anti-
tip bracket.
• Make sure the back leg slides into and
engages the anti-tip bracket.
2
Check for proper installation by grasping the
front edge of the cooktop and carefully
attempting to tilt the range forward.
Test Run
Test the Range Before Use
Check if the range is properly installed and run a
test cycle.
Model LSEL6333*
1
Before using the cooktop for the first time,
clean it with a ceramic cooktop cleaner. This
helps protect the top and makes cleanup
easier.
2
Turn the oven mode knob to the OFF position
to start test.
3
Turn each knob to the Hi position to check
that the surface heating elements are
working properly. The elements should glow
red and radiate heat, and they should cycle on
and off periodically even when the knob is in
the Hi position. This cycling prevents the
glass-ceramic from being cracked by thermal
shock.
NOTE
• The Warm Zone does not consume enough
power to glow red.
