Product Specifications
English 12
Needed Tools and Parts
Parts Needed
Gas line shut-off valve Flexible metal appliance
connector ¹/₂ in (ID) x 5 ft
Flare union adapter
³/₄ in (NPT) x ¹/₂ in (ID)
135-degree elbow (optional) Lag bolt or 1/2-in (OD)
sleeve anchor
Flare union adapter
1/2 in (NPT x 1/2 in (ID)
Tools Needed
Flat-blade screwdriver Phillips screwdriver Open-end or adjustable wrench
Pipe wrench (2) Nut driver Pencil and ruler
Level Pipe joint compound Utility knife
Soapy water solution Drill with ¹/
8
" or 3 /
16
" bit
