All air bag and equipment mounting zone dimensions are approximate
due to different air bag deployment characteristics.
Figure 1
1. 325 mm (12.5 inches) from center of air bag door
2. 375 mm (15 inches) from center of air bag door
3. 700 mm (27.5 inches)
No objects should be placed between the air bags due to air bag
variability.
10
20
30
40
50
60 70
80
90
100
110
120
20
40
60
80
100
120
140
160
180
200
L
P R N D 2 1
1
2
3
