PC100 Terminal User’s Guide
11
RS-485 Multi-Drop
Fig. A – Junction box wiring connect points
See Fig. A
Some junction boxes have
only six connect points
instead of eight
8 points
6 points
PayClock
PayClock
PayClock
Be sure to maintain polarity through out the chain
