4. After rear posts are secured and tightened with a 9/16”
wrench, identify the Rear bar (telescoping tube with 3/8”
pre-drilled holes on either end), and insert into left & right
rear post making sure:
A. Tubes are compatible and match.
B. Pre-drilled holes match those on corner posts
C. Welded nuts face down
5. Secure Rear Bar to Rear Posts using Locking pins, and
hand tighten 3/8” hex head set bolts into the weld nuts on
the underside of the bars & posts.
6. Position left front post as desired, ideally as far forward
as possible and in line with the left rear post. Mark where
the holes are to be drilled on the utility box.
7. Insert one end of the Blank Bar into installed front left
post, and the other end into the right post. Secure right
front post at this time. If Blank Bar is
too long, you will need to trim it at this time.
8. Insert hex head set bolt into all weld nuts and hand
tighten at this time.
9. Bolt two Side Rails together to make a full length side
rail assembly. Repeat for the second rail. Please note the
direction of the labels and assemble rails so they face the
same way. (see below)
Secure with the following: (per side)
2-3/8”- 16x1” Carriage bolt
2-3/8”- flat washer
2-3/8”- lock washer
2-3/8”- hex head nut
10. Install side rail assembly to front and Rear Posts
securing with Clamp, 4 Carriage bolts, 4 lock washers,
4 flat washers and 4 nuts. Tighten with 9/16” wrench.
Step 10 may require the help of another person
to lift side rail and secure to posts.
4
5
9
10
